How it Works
Inside the Brewers Dashboard control panel is a combination of Hardware and Software that work together to give you all the advanced features the system offers. Inside the control panel are two main devices, the BD-ES which is the Embedded server that records and stores all the data and also contains a webserver to allow users to access and control the system. The BD-1084 connects to your tanks and equipment. The Brewers Dashboard control panel can be expanded by adding multiple BD-1084 Controllers depending on how many tanks and other equipment you want to connect.
​
Temperature sensors are installed in each of your tanks and connected to the BD-1084 controller. Each cooling valve is also connected to the BD-1084. You can connect additional equipment like your Chiller, VFD, or Boiler. The BD-1084 can also be configured to control your HLT, CLT, Kettle, and Mash.
​
The Brewers Dashboard can also communicate with other equipment using one of the build-in industrial automation protocols such as Modbus or extract data from a 3rd party database.
​
The Brewers Dashboard is a powerful data acquisition, automation, and visualization system developed by Infinite Automation Systems Inc. Contained in the Brewers Dashboard is a full SCADA (Supervisory, Control and Data Acquisition) software suite that is highly developed and used by 1000s of people around the world across many industries.
![process-removebg-preview.png](https://static.wixstatic.com/media/03c8d8_ece8e72e57a640df89f668d376fb1b60~mv2.png/v1/fill/w_652,h_368,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/process-removebg-preview.png)
Hardware Specifications
![](https://static.wixstatic.com/media/11062b_e2ae833a8eaa43e38e4aa6d32eb3b8f7f000.jpg/v1/fill/w_1293,h_727,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/11062b_e2ae833a8eaa43e38e4aa6d32eb3b8f7f000.jpg)
![MangoES-v2.png](https://static.wixstatic.com/media/03c8d8_503e87a841e742faabaf11c05c46bd3c~mv2.png/v1/fill/w_308,h_240,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/MangoES-v2.png)
BD Embedded Server
Processor: Quad-core 1.7GHz Cortex-A9
Ram: 2 Gigabytes
Disk Type: High-Speed eMMC Flash
Disk Size: 8GB, 16GB, 32GB or 64GB available
Power Input: 9-36 VDC @2-5 Watts
Mount: Built-in Din-rail Clip on Back
Dimensions: H 2” X W 3.8” X D 4”
OS: Linux Built-In RS-485 port with RX TX Lights
![iMod6-removebg-preview_edited.png](https://static.wixstatic.com/media/03c8d8_74a5bf236dfa4050a560512eaedbfc4d~mv2.png/v1/fill/w_308,h_220,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/iMod6-removebg-preview_edited.png)
BD-1084 Programmable Controller
Inputs: 10 Analog 0-5, 4-20mA, Thermistor, Dry
Resolution: 12 bit
Analog Outputs: 4 Analog (0-10V)
Relay Outputs: 8 Dry contacts @24V
Power Input: 12-24 VDC/AC
![pexels-danny-meneses-943096.jpg](https://static.wixstatic.com/media/03c8d8_89dee2a398484d4f82cb1fb6b95a9182~mv2.jpg/v1/crop/x_763,y_0,w_4475,h_4000/fill/w_396,h_354,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/pexels-danny-meneses-943096.jpg)
Software Features
-
Recipe-based Process Control
-
Batch Recording & Reporting
-
24/7 Monitoring with Email Alarms and Reports
-
Real-time Dashboard for Temperature Readings
-
Browser-based User Access
-
Remote Monitoring and Control
-
Individual User Permissions with Audit trail
-
Scripting Environment for Automation and Meta Data
-
Communicates with any equipment using built-in protocols
Communication Protocols
-
Modbus IP
-
Modbus IP Slave
-
Modbus Serial
-
BACnet MS/TP
-
HTTP
-
SNMP
-
SQL
-
ASCII Serial
-
MBus
-
POP3
-
Data Files (XML, CSV, XLS)
-
Allen Bradley®
-
Cloud Sync
